Output Fitler ( OFR)
Production introduction
Ouptui filter can prevent EMI or radio interference to power cable, which come from inverter. Also can prevent EMI and radio interference into inverter, which come from power cable. It can suppress effectively radio interference of voice frequency equipment. the applicable wavelength is
100K to
30MHz.
Production application
The equipment, that can produced strong interference, or sensitive to EMI, request installed power cable filter.
Such as
SCR silicon control rectifier, variable speed drive, motor equipment, switching power supply circuit.
Working environment
Maximum working height:
2000m. if working more than
2000m, current
derating 2% for every
100m higher.
Working temperature:
-25℃to 45℃.comparative moisture not over 90%
No hazardous gas, no inflammables and explosives.
With well-ventilated condition, ventilation devices shall be mounted if installation in panels.
