48VDC high efficiency solar well pumps and DC controller
Automatic dc Submersible Solar Water Pump
DC 24V 48V 72V Solar Pump with Controllers | Solar Panels | |||||||||||||
Model | Rate/Max. Flow (m³/h) | Rate/Max. Head (m) | Input Power (W) | Solar Power (W) | Voltage (V) | Height (mm) | Weight (kg) | Outlet dimater (mm) | Pump diameter | Packing Size(mm) | Power of each panel | Vmp/ VOC (V) | Qty. (PCS) | Connection Way |
mm | ||||||||||||||
3SSW1.8-16-48-120 | 0.5/18 | 9//16 | 120 | 180 | DC48V | 420 | 4.6 | 32 | 75 | 120*120*520 | 250W | 30/36 | 2 | 2pcs in series |
3SSW2-18-48-150 | 0.7/20 | 13/18 | 150 | 225 | 420 | 4.9 | 32 | 75 | 120*120*520 | 250W | 30/36 | 2 | 2pcs in series | |
3SSW2.5-30-48-200 | 0.7/2.5 | 20/30 | 200 | 300 | 440 | 4.6 | 32 | 75 | 120*120*520 | 250W | 30/36 | 2 | 2pcs in series | |
3SSW2.6-40-48-400 | 1/2.6 | 30/40 | 400 | 600 | 440 | 4.9 | 32 | 75 | 120*120*520 | 250W | 30/36 | 2 | 2pcs in series | |
3SSW2.7-52-48-550 | 1/2.7 | 40/52 | 600 | 750 | 510 | 5.3 | 32 | 75 | 120*120*550 | 250W | 30/36 | 4 | 2 rows in parallel of 2 pcs in series, total is 4pcs | |
3SSW3-63-48-600 | 1/3.0 | 48/63 | 600 | 900 | 510 | 5.3 | 32 | 75 | 120*120*550 | 250W | 30/36 | 4 | 2 rows in parallel of 2 pcs in series, total is 4pcs | |
3SSW3-78-48-750 | 1/3.0 | 60/78 | 750 | 1125 | 510 | 5.3 | 32 | 75 | 120*120*550 | 250W | 30/36 | 6 | 3 rows in parallel of 2 pcs in series, total is 6pcs | |
3SSW3-22-48-300 | 2/3.0 | 16//22 | 300 | 450 | 440 | 5.3 | 32 | 75 | 120*120*520 | 250W | 30/36 | 2 | 2pcs in series | |
3SSW4-33-48-550 | 2/4.0 | 22/33 | 550 | 825 | 510 | 5.3 | 32 | 75 | 120*120*550 | 250W | 30/36 | 4 | 2 rows in parallel of 2 pcs in series, total is 4pcs | |
3SSW5-40-48-750 | 2/5.0 | 33/40 | 750 | 1125 | 510 | 5.8 | 32 | 75 | 150*150*550 | 250W | 30/36 | 6 | 3rows in parallel of 2 pcs in series, total is 6pcs |
